WS-C3850-12X48U-L, Cisco Catalyst Switch, 48xGigabit UPOE/12xMulti-Gig/ LAN Base
$6,000
WS-C3850-12X48U-L switch provides 48 x 10/100/1000 with 12 100Mbps/1/2.5/5/10 Gbps UPOE Ethernet ports. It is built in wireless controller provide fully convergence between wired and wireless on a single platform.
| Model | WS-C3850-12X48U-L |
|---|---|
| Brand | Cisco |
| Enclosure Type | Rack-mountable – 1U |
| Ports | 48 x 10/100/1000 with 12 100Mbps/1/2.5/5/10 Gbps UPOE Ethernet ports |
| Network Management Interface | Ethernet management port: RJ-45 connectors, 4-pair Cat-5 UTP cabling Management console port: RJ-45-to-DB9 cable for PC connections |
| Switching Capacity | 472 Gbps |
| Maximum Stacking Number | 9 |
| Stack Bandwidth | 480 Gbps |
| Maximum VLANs IDs | 1,000 |
| MAC Address Table Size | 32K |
| CPU | Multicore CPU |
| RAM | 4 GB |
| Flash Memory | 2 GB |
| Number of AP per Switch/Stack | 100 |
| Number of Wireless Clients per Switch/Stack | 2,000 |
| Total Number of WLANs per Switch | 64 |
| Wireless Bandwidth per Switch | Up to 40 Gbps |
| Supported Aironet AP Series | 3600, 3500, 2600, 1600, 1260, 1140, 1040 |
| Console Ports | USB (Type-B), Ethernet (RJ-45) |
| Expansion Slot(s) | 1 network module slot and 1 power redundant slot |
| Network Modules Selection | C3850-NM-4-1G, C3850-NM-2-10G, C3850-NM-4-10G, C3850-NM-8-10G, C3850-NM-2-40G |
| Stacking Cable | STACK-T1-50CM, STACK-T1-1M, STACK-T1-3M |
| Stack Power Cable (recommended) | CAB-SPWR-30CM, CAB-SPWR-150CM |
| Power Supply | PWR-C1-1100WAC |
| Available PoE Power | 630W |
| Power Device | Power supply – redundant – plug-in module |
| Power Redundancy | optional |
| Dimension | 4.45 x 44.5 x 48.8 cm (1.75 x 17.5 x 19.2 in) |
| MTBF in Hours | 202,030 |
| Compliant Standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.1X-Rev, IEEE 802.11, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, RMON I and II, SNMP v1, v2c, v3 |
| System Software | IOS IP Base (Upgradable) |
| EnergyWise License | ENERGY-MGMT, ENERGY-MGT-100-K9 |
| Technical Support and Services | Cisco SMARTnet Service, Cisco Smart Foundation Service, Cisco SP Base Service, Cisco Focused Technical Support Services |
| Operating Temperature up to 5,000 ft (1,500 m) | 23°F to 113°F (-5°C to +45°C) |
| Operating Temperature up to 10,000 ft (3,000 m) | 23°F to 104°F (-5°C to +40°C) |
| Operating Temperature up to 6,000 ft (1,800 m) | 23°F to 113°F (-5°C to +45°C) |
| Operating Temperature up to 13,000 ft (4,000 m) | 23°F to 95°F (-5°C to 35°C) |
