WS-C3850-12S-S, Cisco Catalyst Switch, 12 SFP/Layer 3/IP Base
$8,624
Cisco Catalyst WS-C3850-12S-S is the next generation enterprise-level stackable switch that is integrated with 12 SFP ports in IP base feature set.
| Model | WS-C3850-12S-S |
|---|---|
| Brand | Cisco |
| Enclosure Type | Rack-mountable – 1U |
| Ports | 12 x SFP ports |
| Network Management Interface | Ethernet management port: RJ-45 connectors, 4-pair Cat-5 UTP cabling, Management console port: RJ-45-to-DB9 cable for PC connections |
| Available PoE Power | None |
| Switching Capacity | 68 Gbps |
| Maximum Stacking Number | 9 |
| Stack Bandwidth | 480 Gbps |
| Forwarding Performance | 68.4 Mpps |
| FNF Entries | 48,000 flows |
| Maximum VLANs IDs | 1,000 |
| MAC Address Table Size | 32K |
| CPU | Multicore CPU |
| RAM | 4 GB |
| Flash Memory | 2 GB |
| Number of AP per Switch/Stack | 100 |
| Number of Wireless Clients per Switch/Stack | 2,000 |
| Total Number of WLANs per Switch | 64 |
| Wireless Bandwidth per Switch | Up to 20 Gbps |
| Supported Aironet AP Series | 3600, 3500, 2600, 1600, 1260, 1140, 1040 |
| Console Ports | USB (Type-B), Ethernet (RJ-45) |
| Expansion Slot(s) | 1 network module slot and 1 power redundant slot |
| Network Modules Selection | C3850-NM-4-1G: 4 x 1G uplinks network module, C3850-NM-2-10G: 2 x 10G or 4 x 1G uplinks network module |
| Stacking Cable | STACK-T1-50CM StackWise stacking cable with a 0.5 m length, STACK-T1-1M StackWise stacking cable with a 1.0 m length, STACK-T1-3M StackWise stacking cable with a 3.0 m length |
| Stack Power Cable (Recommended) | CAB-SPWR-30CM stack power cable with a 30CM length, CAB-SPWR-150CM stack power cable with a 150CM length |
| Power Supply | PWR-C1-350WAC |
| Power Device | Power supply – redundant – plug-in module |
| Power Redundancy | Optional |
| Voltage Range (Auto) | 100V-240V |
| Power Consumption of Standalone | 109.75 W (Max) |
| MTBF | 315,840 hours |
| Compliant Standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.1X-Rev, IEEE 802.11, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, RMON I and II, SNMP v1, v2c, v3 |
| System Software | IOS IP Base (Upgradable) |
| EnergyWise License | ENERGY-MGMT, ENERGY-MGT-100-K9 |
| Software License | C3850-12-S-E: IP Base to IP Services RTU paper license, L-C3850-12-S-E: IP Base to IP Services RTU electronic license |
| Access Point Licenses | L-LIC-CT3850-UPG: Primary upgrade license for Cisco 3850 wireless controller (e-delivery), L-LIC-CTIOS-1A: 1 AP adder license for Cisco IOS Software based wireless controller (e-delivery), LIC-CT3850-UPG: Primary upgrade license for Cisco 3850 wireless controller (paper license), LIC-CTIOS-1A: 1 AP adder license for Cisco IOS Software based wireless controller (paper license) |
