Lenovo ThinkEdge SE450, 3rd Gen Intel® Xeon® Platinum 36 cores, 10x DDR4 slots; Max 1TB w/ 8x 128GB RDIMMs

ThinkEdge SE450 Specifications

• Lenovo

• SE450

• Up to 1x 3rd Gen Intel^® Xeon^® Platinum processor, up to 36 cores, up to 225W TDP

• 10x DDR4 memory slots; Maximum 1TB using 8x 128GB 3DS RDIMMs; Supports up to 2x Intel^® Optane™ Persistent Memory 200 Series modules (PMem)

• Up to 4x single-width GPUs or 2x double-width GPUs

• Front: 1x Power Button, 1x system locator, health with LED, 1x VGA, 2x USB 3.1, 1x Serial Port (optional), 1x RJ-45 1Gb for dedicated management, 1x system locator LED Optional WIFI (management)

• Dual redundant power supplies AC (up to 1800W Platinum) or Dual redundant power supplies -48V DC 1100W

• 2U rack server 300mm (11.8in) depth with 4 FHHL adapter or 2U rack server 360mm (14.2in) depth with 4 FHFL adapter

• Up to 6x 2.5-inch 7mm drives; Up to 6x NVMe drives supported; 2x M.2 boot drives (RAID 1)

• LOM adapter installed in the OCP 3.0 slot; PCIe adapters

• PFA; hot-swap/redundant drives and power supplies; redundant fans; internal light path diagnostic LEDs; front-access diagnostics via dedicated USB port; optional External Diagnostics Panel Handset with LCD display

• Root of Trust (RoT) module includes Platform Firmware Resiliency (PFR), Trusted Platform Module (TPM) 2.0 or TCM for PRC and optional Chassis Intrusion Switch. Secures and authenticates the system to prevent unauthorized intrusion.

• Support for ThinkSystem PCIe RAID/HBA cards

• Air-cooled with N+1 hot-swap fan solution

• Lenovo XClarity Controller

• Microsoft, Red Hat, Ubuntu, SUSE, VMware. Visit lenovopress.com/osig for more information

• 10°C to 55°C

• 1- and 3-year customer replaceable unit and onsite service, next business day 9×5, optional service upgrades
