Dell R650 Server, 1U/8xSFF/Scalable CPU/DDR4
$5,450
Dell R650 8SFF Server
Product Details
The Dell EMC PowerEdge R650, powered by 3rd Generation Intel Xeon Scalable processors, is designed to optimize workloads performance and data center density.
Optimal performance, high scalability, and data center density for demanding workloads
The dual-socket/1U PowerEdge R650 is the ideal rack server to address performance, high scalability, and density.
* Supports 8 channels per CPU, up to 32 DDR4 DIMMs at 3200 MT/s DIMM speed
* Address substantial throughput improvements with PCIe Gen 4 and up to 10 NVMe drives
* Ideal for traditional corporate IT, database and analytics, VDI, and AI/ML and Inferencing
* Optional Direct Liquid Cooling support to address high wattage processors
Configuration of Dell R650 8SFF Server.
| Configuration | Processor | Memory | Hard Drive | Power Supply |
| Dell 1U R650 1*4310 8SFF Server | 1 * Intel Xeon 4310 | 1 * 32G | 1*1.2T SAS 10K | 1*800W |
| Dell 1U R650 1*5317 8SFF Server | 1 * Intel Xeon 5317 | 1 * 32G | 1*1.2T SAS 10K | 1*800W |
| Dell 1U R650 1*6330 8SFF Server | 1 * Intel Xeon 6330 | 1 * 32G | 1*1.2T SAS 10K | 1*800W |
the R650 vs R640.
| Series | Dell EMC PowerEdge R650 | Dell EMC PowerEdge R640 |
| Processor | Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor | Up to two 2nd Generation Intel Xeon Scalable processors, up to 28 cores per processor |
| Memory | 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 4 TB max, speeds up to 3200 MT/s Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max Supports registered ECC DDR4 DIMMs only |
24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2933 MT/s, 3TB max Up to 12 NVDIMM, 192 GB Max Up to 12 Intel Optane persistent memory PMem, 6.14TB max, (7.68TB max with PMem + LRDIMM) Supports registered ECC DDR4 DIMMs only |
| Storage controllers | Internal controllers: PERC H745, HBA355I, S150, H355, H345, H755, H755N Boot Optimized Storage Subsystem (BOSS-S1): HW RAID 2 x M.2 SSDs 240 GB or 480 GB Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB External PERC (RAID): PERC H840, HBA355E |
Internal Controllers: PERC H330, HBA330, HBA350i (adapter only), H730P, H740P, H750 (adapter only) External Controllers: H840, 12 Gbps SAS HBA, HBA355e (adapter only, non-RAID) |
| Drive Bays | Front bays: Up to 10 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 153 TB Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.8 TB Rear bays: Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.7 TB |
Front drive bays: Up to 10 x 2.5” SAS/SATA (HDD/SSD) with up to 8 NVMe SSD max 76.8TB or up to 10 NVMe drives max 64TB, or up to 4 x 3.5” SAS/SATA HDD max 64TB Rear drive bays: Up to 2 x 2.5” SAS/SATA (HDD/SSD), NVMe SSD max 15.36TB Optional DVD-ROM, DVD+RW |
| Power Supplies | 800 W Platinum AC/240 Mixed Mode 1100 W Titanium AC/240 Mixed Mode 1400 W Platinum AC/240 Mixed Mode 1100 W DC -48 – 60 V |
495W Platinum 750W Platinum 750W 240HVDC Platinum* 1100W 48VDC 1100W Platinum 1100W 380HVDC Platinum* 1600W Platinum 750W Titanium Hot plug power supplies with full redundancy option Up to 8 hot plugs fans with full redundancy *Available in China and Japan only |
| Recommended Server | Dell R650 8SFF Server | Dell 1U R640 5218/8G*1/600G SAS 10K*1/H330/DVD/750W*1/2.5-8 |
Dell R650 8SFF Server Specification |
|
| Processor | Up to two 3rd Generation Intel® Xeon® Scalable processors with up to 24 cores per processor |
| Operating System | (Dell Technologies recommends Windows 11 Pro for business)
Canonical® Ubuntu® Server LTS Citrix® Hypervisor® Microsoft® Windows Server® with Hyper-V Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi® |
| Chipset | Intel®C620A chipset |
| Accelerators | Up to three 75 W single-width GPU |
| Memory | DIMM Speed
Up to 3200 MT/s
Memory Type RDIMM LRDIMM NVDIMM Intel® Persistent Memory 200 series (BPS)
Memory Module Slots 32 DDR4 DIMM slots
Maximum RAM RDIMM 2 TB LRDIMM 4TB NVDIMM 128 GB Intel® Persistent Memory 200 series (BPS) 8TB |
| Storage | Front Bays
Up to 10 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 153 TB Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.8 TB Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB
Rear bays Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.7 TB |
| Storage Controllers | Internal Controllers
PERC H745, H345, HBA355I, H755, H755N
External Controllers PERC H840, HBA355E
Software RAID S150
Internal Boot Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs 240 GB or 480 GB Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2 x M.2 SSDs 240 GB or 480 GB Internal Dual SD Module or Internal USB 3.0 |
| Security
|
Cryptographically signed firmware
Secure Boot Secure Erase Silicon Root of Trust System Lockdown (requires iDRAC9 Enterprise or Datacenter) TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
| Management | Embedded / At-the-Server
iDRAC9 iDRAC Service Module iDRAC Direct Quick Sync 2 wireless module
Consoles OpenManage Enterprise OpenManage Power Manager plugin OpenManage SupportAssist plugin OpenManage Update Manager plugin
Mobility OpenManage Mobile
Tools iDRAC RESTful API with Redfish IPMI RACADM CLI System Update Utility Update Catalogs
OpenManage Integrations BMC® Truesight Microsoft® System Center Red Hat® Ansible® Modules VMware® vCenter and vRealize Operations Manager
OpenManage connections IBM Tivoli® Netcool/OMNIbus IBM Tivoli® Network Manager IP Edition Micro Focus® Operations Manager Nagios Core Nagios® XI |
| Power Supplies | 800 W Platinum AC/240 V Mixed Mode
1100 W Titanium AC/240 V Mixed Mode 1400 W Platinum AC/240 V Mixed Mode 1100 W DC -48 – 60 V Hot plug power supplies with full redundancy option |
| Ports | Network Options
2 x 1 GbE LOM and 1 x OCP 3.0 (x8 PCIe lanes) (optional)
Front Ports 1 x iDRAC Direct (Micro-AB USB) port 1 x USB 2.0 1 x VGA
Rear Ports 1 x USB 2.0 1 x USB 3.0 1 x Serial (optional) 2 x RJ-45 1 x VGA (optional for liquid cooling configuration)
Internal Ports 1 x USB 3.0 (optional) |
| Slots
|
Up to 3 x PCIe Gen4 low profile slots (all x16 except one x8 slot with SNAPI I/O option) or 2 x PCIe (Gen4) full height slots
Video Card 1 x VGA (optional for liquid cooling configuration) |
| Bezel | Optional LCD bezel or security bezel |
| Form Factor | 1U rack server |
| Dimensions & Weight | Height
42.8 mm (1.68 inches)
Width 482 mm (18.97 inches)
Depth 809 mm (31.85 inches) – without bezel 822.84 mm (32.39 inches) – with bezel
Weight 21.2 kg (46.7 lbs) |
| Rack Support | ReadyRails II sliding rails with optional cable management arm (CMA) and strain relief bar (SRB) for 4-post racks. |
| Recommended Support | Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. |
