Dell PowerEdge R470 Datacenter Server 1U, Customizeable : 1 x Intel® Xeon® 6 6700P/6500P/6700E, 16 x 256 GB DDR5 (4 TB), 245 TB,
$0
The Dell PowerEdge R470 is a 1U, single-socket rack server engineered for high-performance computing with optimal
power efficiency and balanced performance, driving cost savings and boosting data center productivity. Its advanced
design maximizes rack utilization by offering more cores in a single socket enabling better performance in a smaller
footprint while minimizing energy consumption. This makes it ideal for workloads like cloud scale web and app
microservices, data services, virtualization, and scale-out database. Purpose-built for enterprise and scalable infrastructures, the PowerEdge R470 seamlessly integrates into existing
environments. Equipped with an Intel® Xeon® processor with E-cores that are tailored for energy efficiency and
performance-per-watt, offering both improved power efficiency and higher rack density. With GPU support, it further
enhances computational power while reducing overall operational costs, especially on energy consumption impact.
Dell PowerEdge R470 Data Center Server // ( Customizable)
Product Features
The Dell PowerEdge R470 is powered by Intel Xeon 6 Processors, DDR5
Memory, NVMe BOSS, Energy Star compliant and advanced cooling.
Ideal for:
• Cloud scale web and app microservices
• Data services
• Virtualization
• Scale-out database
Specifications Details
Dell PowerEdge R470 Data Center Server Specifications |
|
| Processor | One Intel® Xeon 6 E-core processor with up to 144 cores per processor or One Intel® Xeon 6 P-core processor with up to 86 Cores with R1S option |
| Processor Speed | 2.8 GHz |
| Total Memory | • 16 DDR5 DIMM slot, supports RDIMM 4TB max, speeds up to 6400 MT/s • Intel® Xeon® 6 E-core processor – supports 1 TB max • Intel® Xeon® 6 P-core processor with up to 86 cores with R1S option – supports 4 TB max • Supports registered ECC DDR5 DIMMs only Note: The installed processor may reduce the operating speed of the DIMM |
| Memory Type | DDR5 |
| Storage Type | SSD |
| Storage Capacity | Internal Controllers (RAID): PERC H365i DC-MHS, front PERC H965i DC-MHS, PERC H365i adapter, PERC H965i adapter • External Controllers: HBA465e, H965e(RAID) • Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS): HWRAID 1, 2 xM.2 NVMe SSDs, M.2 interposer with upto 2 x M.2 NVMe SSDs or USB Front bays:
|
| Drive Interface | SATA |
| RAID Support | Rear bays: • Up to 4 x EDSFF E3.S Gen5 NVMe max 245.76 TBPower Supplies • 800 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1100 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1500 W Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1500 W 277 Vac and HVDC Titanium, hot swap redundant • 1400 W -48 VDC, hot swap redundant • 1800 W Titanium 100-240 VAC or 240 HVDC, hot swap redundant |
| Expansion Slots | Up to 8 PCIe 4.0 slots |
| Networking | Dual-port 10GbE |
| Power Supply | Dual redundant power supplies |
| Form Factor | 1U Rack |
| Remote Management | iDRAC • iDRAC Direct • iDRAC RESTfull API with redfish • RACADM CLI • iDRAC Service Module |
| Operating System and Hypervisor | • Canonical Ubuntu Server LTS • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi • Windows Server • Windows Server Datacenter For specifications and interoperability details, see Dell.com/OSsupport |
| Connection Ports | Front Ports • 1 x USB 2.0 Type – C port • 1 x USB 2.0 Type A port (optional) • 1 x Mini-DisplayPort (optional) • 1 x DB9 Serial (with front I/O configuration) • 1 x Dedicated BMC Ethernet port (with front I/O configuration) Rear Ports Internal Port PCIe Up to six PCIe slots (x16 connector) |
| Cooling | Cooling Options Air cooling Fans • Up to 4 shot plug fans |
| Security | • Cryptographically signed firmware • Data at Rest Encryption (SEDs with local or external key mgmt) • Secure Boot • Secured Component Verification (Hardware integrity check) • Secure Erase • Silicon Root of Trust • System Lockdown • TPM 2.0 FIPS, CC-TCG certified• Chassis Intrusion DetectionGPU Options Up to 3 x 400W DW; Up to 4 x 75W SW DPU Options NVIDIA BlueField-3 2 x 200 GbE B3220 |
| Dimensions (H x W x D) | • Height – 42.8 mm (1.69 inches) • Width – 482 mm (19.0 inches) • Depth – 816.92 mm (32.16 inches) with bezel • Depth – 815.14 mm (32.09 inches) without bezel • Depth (Front I/O Configuration) — 829.44 mm (32.09 inches) without bezel Note: Front I/O configuration will not have a bezel |
| Warranty | Standard 3-Year Warranty |
| Hot Plug | Hot Plug Power Supplies & Drives |
| Power Supply | • 800W Platinum/Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1100 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1500 W Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1500 W 277 Vac and HVDC Titanium, hot swap redundant • 1400W -48v DC Titanium, hot swap redundant |
