SFP-OC12-LR2, Cisco SFP Module, OC-12/STM-4, 80km, Long Reach
$1,485
Cisco OC-12/STM-4 Pluggable long-reach (80 km) transceiver module, 1550-nm wavelength, LC connector. Cisco SFP-OC12-LR2 This Single-mode long range (LR-1)module used with the OC-12 ATM Line Card with Distance range 1550nm. Cabling distance miles (80 km), Connectors Multimode fiber-optic: LC-type connector Single-mode fiber-optic: LC-type connector.
Cisco SFP-OC12-LR2
Cisco OC-12/STM-4 Pluggable long-reach (80 km) transceiver module, 1550-nm wavelength, LC connector. Cisco SFP-OC12-LR2 This Single-mode long range (LR-1)module used with the OC-12 ATM Line Card with Distance range 1550nm. Cabling distance miles (80 km), Connectors Multimode fiber-optic: LC-type connector Single-mode fiber-optic: LC-type connector.
Specifications Detail
SFP-OC12-LR2 Specification |
|
| General | |
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Networking | |
| Connectivity Technology | Wired |
| Data Transfer Rate | 622.08 Mbps |
| Optical Wave Length | 1550 nm |
| Line Rate | OC-12/STM-4 |
| Max Transfer Distance | 49.9 miles / 80 KM |
| Expansion / Connectivity | |
| Interfaces | 1 x OC-12/STM-4 – LC/PC single-mode x 2 |
| Compatible Slots | 1 x SFP (mini-GBIC) |
| Dimensions & Weight | |
| Width | 0.6 in |
| Depth | 0.2 in |
| Height | 0.4 in |
| Manufacturer Warranty | |
| Service & Support | Limited warranty – 90 days |
| Environmental Parameters | |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 185 °F |
